Neutrik NP3TT-P-B Bantam Miniature Jack 3-Pole Connector
In Stock
NU-NP3TT-P-B
| Buy In Bulk & Save! | |
|---|---|
| Buy 2 to 5: | Pay $9.66 |
| Buy 6 to 14: | Pay $9.35 |
| Buy 15 or more: | Pay $9.06 |
Enter Post Code to Calculate Shipping Cost & ETA
Shop Now. Pay Later.
Always interest-free.
Add your favourites to cart
Select Afterpay at checkout
Log into or create your Afterpay account, with instant approval decision
Your purchase will be split into 4 payments, payable every 2 weeks
All you need to apply is to have a debit or credit card, to be over 18 years of age, and to be a resident of country offering Afterpay
Late fees and additional eligibility criteria apply. The first payment may be due at the time of purchase
For complete terms visit afterpay.com/terms
SHOP NOW • PAY LATER • 100% INTEREST FREE
The perfect connector for all of your bantam cable needs. Genuine Neutrik, 3-pole black connector, ideal for use with TT patch panels. This is a redesign of the NP3TT-1 connector.
| Loading... | ||||||
Neutrik NP3TT-P-B Bantam Miniature Jack 3-Pole Connector
The perfect connector for all of your bantam cable needs. Genuine Neutrik, 3-pole black connector, ideal for use with TT patch panels. This is a redesign of the NP3TT-1 connector.
Bantam Connector
4.4 mm tiny telefone plug bantam type, solder termination for T+R, hex crimp of S with a standard RG58 crimp tool, black plastic housing, Nickel contacts. Ideal use with TT patch panels.
Features:
- Designed for pro audio applications
- Robust egonomic design - long-lasting and depenableStandard
- HEX crimp cable clamp for shield termination and cable retention
- Colored sleeves available for coding and marking
Specifications:
| Product | |
| Title | NP3TT-P-B |
| Connection Type | Plug |
| Gender | male |
| Electrical | |
| Contact resistance | depends on mating connector mΩ |
| Dielectric strength | 1 kVdc |
| Insulation resistance | > 2 GΩ (initial) |
| Rated current per contact | depends on mating connector A |
| Rated voltage | < 50 V |
| Mechanical | |
| Cable O.D. | 4 - 4.8 mm |
| Crimp size | 5,41 Hex crimp (shield) acc. IEC 60803 (die designation D) |
| Lifetime | > 1000 mating cycles |
| Wiresize | 0,25 mm² |
| Wiresize | 24 AWG |
| Wiring | Solder contacts |
| Material | |
| Contact plating | 2 µm Ni (Su) |
| Contacts | Bronze (CuSn6) (Tip) |
| Shell | Polyamide (6 30% GR) (black) |
| Insulation | Polyamide (PA 6.6 30 % GR) |
| Environmental | |
| Standard compliance | MIL-P-642/13 |
| Solderability | Complies with IEC 68-2-20 |
| Temperature range | -20 °C to +65 °C |
