Neutrik NC4FD-LX 4-Pin XLR Female Panel Mount Connector
In Stock
NU-NC4FD-LX
| Buy In Bulk & Save! | |
|---|---|
| Buy 2 to 5: | Pay $11.63 |
| Buy 6 to 14: | Pay $11.29 |
| Buy 15 or more: | Pay $10.96 |
Enter Post Code to Calculate Shipping Cost & ETA
Shop Now. Pay Later.
Always interest-free.
Add your favourites to cart
Select Afterpay at checkout
Log into or create your Afterpay account, with instant approval decision
Your purchase will be split into 4 payments, payable every 2 weeks
All you need to apply is to have a debit or credit card, to be over 18 years of age, and to be a resident of country offering Afterpay
Late fees and additional eligibility criteria apply. The first payment may be due at the time of purchase
For complete terms visit afterpay.com/terms
SHOP NOW • PAY LATER • 100% INTEREST FREE
Neutrik NC4FD-LX 4-Pin XLR Female panel mount, with solder cups, nickel housing and silver contacts. The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding.
| Loading... | ||||||
Neutrik NC4FD-LX 4-Pin XLR Female DLX Series with Solder Terminals and Latch
Neutrik NC4FD-LX 4-Pin XLR Female panel mount, with solder cups, nickel housing and silver contacts. The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding.
The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding.
Fetaures:
- All metal housing offers best overall RF protection and electromagnetic shielding
- Duplex ground contact for excellent contact integrity between chassis and cable connector
- Female contact incorporates a solder barrier to prevent solder running into the contact mating area
- Larger solder contacts for easier termination
- Optional connection to easily join pin1 to chassis ground
- D-style housing provides installation compatibility with industry standard D mounting dimensions
Specifications:
| Connection Type | XLR |
| Gender | Female |
| Capacitance between contacts | ≤ 7 pF |
| Contact resistance | ≤ 5 mΩ |
| Dielectric strength | 1,5 kVdc |
| Insulation resistance | > 10 GΩ (initial) |
| Rated current per contact | 10 A |
| Rated voltage | < 50 V |
| Lifetime | > 1000 mating cycles |
| Wiring | Solder contacts |
| Locking device | Latch lock |
| Chassis shape | D |
| Shell | Zinc diecast (ZnAl4Cu1) |
| Shell plating | Nickel |
| Standard compliance | IEC 61076-2-103 |
| Protection class | IP 40 |
