Neutrik NC3MD-LX-M3 Male 3-Pin DLX-Series with M3 Threaded Mounting

Neutrik

Neutrik NC3MD-LX-M3 Male 3-Pin DLX-Series with M3 Threaded Mounting

$8.99
RRP $10.80
  In Stock
or interest free for up to 6 months with
Buy In Bulk & Save!
Buy 2 to 5: Pay $8.70
Buy 6 to 14: Pay $8.43
Buy 15 or more: Pay $8.17
-
+

The Neutrik NC3MD-LX-M3 Male 3-Pin is part of their DLX Series which features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. industry standard D mounting dimensions.



Dispatch

Neutrik NC3MD-LX-M3 Male 3-Pin DLX-Series with M3 Threaded Mounting
The Neutrik NC3MD-LX-M3 Male 3-Pin is part of their DLX Series which features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. industry standard D mounting dimensions.

The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector. 3 pole female receptacle, solder cups, Nickel housing, silver contacts, M3 mounting holes

Features:

  • All metal housing offers best overall RF protection and electromagnetic shielding
  • Duplex ground contact for excellent contact integrity between chassis and cable connector
  • Male connector's retention bar replaces plastic design with all metal version improving pull-out force
  • Larger solder contacts for easier termination
  • Optional connection to easily join pin1 to chassis ground
  • D-style housing provides installation compatibility with industry standard D mounting dimensions

Specifications:

Electrical
Capacitance between contacts ≤ 4 pF
Contact resistance ≤ 5 mΩ
Dielectric strength 1,5 kVdc
Insulation resistance > 10 GΩ (initial)
Rated current per contact 16 A
Rated voltage < 50 V
Mechanical
Insertion force ≤ 20 N
Withdrawal force ≤ 20 N
Lifetime > 1000 mating cycles
Wiresize max. 2.5 mm²
Wiresize max. 14 AWG
Wiring Solder contacts
Locking device Latch lock
Mounting direction Rear mounting
Chassis shape D
Mounting Mounting holes with M3 threads
Material
Contact plating 2 µm Ag
Contacts Brass (CuZn35Pb2)
Insert Polyamide (PA66)
Locking element Steel Ck67
Shell     Zinc diecast (ZnAl4Cu1)
Shell plating Nickel
Environmental
Flammability UL 94 V-0
Standard compliance IEC 61076-2-103
Protection class IP 40
Solderability Complies with IEC 68-2-20
Temperature range -30 °C to +80 °C
View PDF brochure for Neutrik NC3MD-LX-M3 Male 3-Pin DLX-Series with M3 Threaded Mounting

Be The First To Review This Product!

Help other SWAMP Industries users shop smarter by writing reviews for products you have purchased.

Write a product review


MPN: NC3MD-LX-M3

ID: 345398
