Foxgear T7E Baby 4-Head Stereo Vintage Echo Guitar Effects Pedal

Foxgear T7E Baby 4-Head Stereo Vintage Echo Guitar Effects Pedal
Any Pink Floyd fan will fall over for this Echorec classic for its exotic echo tones. The Foxgear T7E Baby 4-Head Stereo Vintage Echo Guitar Effects Pedal has a "Binson- inspired” circuit featuring 3 working modes Echo, Repeat, and Swell. Full stereo I/O.

4-Head Stereo Vintage Echo
After the great success of the Echosex Baby, Foxgear pushed the next project, the FOXGEAR T7E Baby to the max, expanding on the features of the famous “Binson- inspired” circuit, plus with the complete palette of options that the original Binson Echorec T7E offered, with a full 4 heads combination. It features 3 working modes Echo, Repeat, Swell, and the ability to recall the Swell mode as a “preset” with a dedicated footswitch. The Foxgear T7E Baby is equipped with full stereo input & output, and an internal stereo engine that works on a phase and split-frequency resulting in an unbelievable stereo 3D effect for an outstanding and lush ambient tone. The Motor Speed control lets you increase the overall delay time, you can mimic a slowed speed of the magnetic drum. This allows the FOXGEAR T7E BABY over 880ms of long, lush delay, keeping the 4 heads in sync, no matter what combination of heads you are using.

Great Design
The Foxgear pedals have a clever design, reducing the footprint, with the use of top mounted jacks, making it easy to hook up into your signal chain. An acrylic faceplate lights up when the pedal is turned on so you'll see it on the darkest of stages. Foxgear pedals are constructed with non-SMD components in the audio path, with analog design, and high-quality components like Wima capacitors, real Alpha 16mm pots, non-plastic trimmers, and a true bypass circuit that includes Panasonic golden pin relays. That’s why all Foxgear pedals are covered with a full 5 Year warranty.

Foxgear Pedals
The best pro musicians on earth have chosen Foxgear for their tone. From Dave Gilmour, Steve Lukather and Adrian Belew, you would have heard the unique tones from musicians who perform with Pink Floyd and Toto through to Rihanna and Katy Perry! Foxgear produce some of the most iconic pedals for guitarists and bassists. The company has its roots in Italy where it is part of a family that includes the boutique Gurus and Baroni-Lab brands, known for creating high end boutique pedals and amps. With Foxgear, you will find professional quality pedals at unusually low prices.

Specifications:

• Power In: 12VDC (negative TIP)
• Consumption at 9V: 140mA
• Delay Time: (H1:86ms, H2:172ms, H3:258ms, H4:344ms)
• Speed Motor Adj: From 344ms to 882ms
• Input Impedance: <=1M Ohm
• Output Impedance: <=10K Ohm
• Length: 90mm
• Width: 127mm
• Height: 30mm
• Rohs Compliance: Yes
• Power Supply: Included
• Weight: 0.5kg
