CVM-AX3 Multi-Interface Audio Mixer
The AX3 mixer breaks the previous single interface limit and adopts the latest multi-interface mixing technology. The XLR combo jacks, along with the 3.5mm provides fully professional connections easily and quickly, supporting 2 XLR mics or wireless mics. Provided with a cold shoe port on both sides and top side, and equipped with standard 1/4 and 3/8 threaded ports on the bottom. These interface settings allow you to deal with more complex and professional shooting environments.
9V Battery/Phantom Power
It is equipped with battery power system, which can adjust the phantom electricity or battery power freely. Let the choice without obstacle and more professional.
Dual Gain-Control Knobs
Multi-channel audio is inputting through AX3 sound channel, AX3 can be separately gain adjustment for each channel.
Features:
- Dual XLR/6.35mm/3.5mm Mics Audio Mixer
- Support Phantom Power
- Support real-time monitoring
- Dual Gain-control knobs
- Mono/Stereo output switch
- Designed with working status indicator
- 9V Battery/Phantom Power/3V Plug-in-power
- External port & hot shoe mount
- Aluminum alloy material
Specifications:
- Input: XLR x 2(L/R), 6.35mm x 2(L/R), Mono x 2(L/R), Stereo x 1(S), AUX
- Output : 3.5mm audio output, 3.5mm headphone output
- Frequency Response : 20Hz~20kHz, ±1dB
- THD+Noise: <0.02%, RL=2kΩ, f=20Hz~20kHz, Vo=1Vrms
- Battery: 9V 6LR61/6F22 x 1
- Size: 123 x 71 60.6mm
- Working Temperature: 0°C ~ +50°C
- Memory Temperature: -20°c ~ +60°C
