The Canare Star Quad mic cable is the best option for all handheld microphone applications. This listing is for 1 Metre (1m) of cable.
| Loading... | ||||||
Canare Star Quad Microphone Cable (Per Metre) - Orange
The Canare Star Quad mic cable is the best option for all handheld microphone applications. It's flexible, smooth-to-the-touch, and yet durable and reliable. This standard 21 AWG cable fits perfectly in all XLR-type audio connectors. Forty separate strands in each conductor eliminate breakage due to flexing. Available in 10 matte finish color jackets.
This listing is for 1 Metre (1m) of cable. For custom length, purchase multiple quantities.
Features:
- Braided Copper Shield
- Flexible in Extreme Cold Weather
- Cross Linked PE Insulation
- Reduced Handling Noise
- Rejects EMI and RFI
- 10 Matte Color Jacket Selections
Applications:
- Microphones
- Portable Applications
- Audio Rack Wiring
- PA Systems
- Audio Patch Cords
|
|
||||||||||
| Model | Std. Lng. ft. (m) |
Wt Std. Lng. lbs (kgs) |
Nom. O.D. in. (mm) |
Jacket Nom. Thick. in. (mm) |
Brittle Point F° (C°) |
No. of Cond. |
Insul. Type* Thick mil |
Cond-AWG (Qty./mil) Cross Sec. Area mil.² **Quad AWG |
Pitch Twist Quad in. (mm) |
Shield Cover- age |
| L-4E6S | 656ft (200m) 1000ft (305m) |
24 (11) 35 (16) |
.236 (6.00) |
PVC .044 (1.12) |
-56 (-49) |
4 2 Blue 2 Wht |
IPE 15.7 |
AC - #24 40/3.15 310 #21 |
.79 (20) |
>95% TAC Braid |
*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.
**Effective AWG of combined twin conductors.
|
|
|||||||
| Model | Cond. D.C.R. ohm/1000ft (ohm/100m) |
Shield D.C.R. ohm/1000ft (ohm/100m) |
Nom. Cap. *** pF/ft (pF/m) |
Nom. Cap. † pF/ft (pF/m) |
Nom. Imp. (ohm) |
Nom. Atten. V/1000ft (V/100m) |
Group Delay Time nS/ft (nS/m) |
| L-4E6S | <29.9 (<9.8) |
<9.1 (<3.0) |
46 (150) |
57 (185) |
44 | 0.9 (0.3) |
1.80 (5.9) |
***Capacitance between twin Blue and twin White conductors.
†Capacitance between conductors to shield.
