Canare DA206 110 Ohm Digital Audio Cable 100m Roll
XMAS DEALS - 800+ ITEMS ON SALE - SAVE 30% ON EXPRESS POST*
Filter

Canare

Canare DA206 110 Ohm AES/EBU Digital Audio Cable - BLUE - 100m Roll

$619.99
RRP $718.00
  In Stock
-
+
Finance Available
PayPal Checkout
Afterpay

Industry standard 110 ohm cable, the DA206 consists of twisted pair conductors with an external braided shield allowing for a flexible cable that reduces the possibility of signal interference.



Dispatch

Canare DA206 110 Ohm AES/EBU Digital Audio Cable - Blue - 100 metre roll
Robustly constructed by one of the worlds leading cable manufacturers, this cable is a smart choice for all professional digital audio applications. The DA206 consists of twisted pair conductors with an external braided shield allowing for a flexible cable that reduces the possibility of signal interference.

Designed to carry Digital Signals- AES/EBU or DMX
The DA206 was designed as a dual purpose cable, that can carry either digital audio (AES/EBU) or DMX lighting signals.

Features:

  • Twisted Pairs with Braided Shield
  • Special PE Filter Rods maintain constant 110 ohm impedance

Applications:

  • AES/EBU Digital Audio
  • DMX Lighting
  • Audio Rack Wiring
  • Post Productions

Specifications:

  • Maximum recommended AES/EBU length: 1,180ft (360meters).
  • Jacket color: BLUE

MECHANICAL SPECIFICATIONS

Model Std.
Lng.

ft.
(m)
Wt.
Std. Lng.

lbs.
(kgs)
Nom.
O.D.

in.
(mm)
PVC
Jacket
Nom.
Thick.
in.
(mm)
Brittle
Point


(C°)
No.
of
Cond.
Insul.
Type*
Thick

mil
Cond-AWG
(Qty./mil)
Cross Sec.
Area
mm²
Pitch
of
Quad
in.
(mm)
Shield
Cover-
age
DA206 328
(100)

656
(200)
17
(8)

35
(16)
.287
(7.3)
.035
(0.9)
-56
(-49)
2
ORG
WHT
IPE
30.3
AC-#20
(7/12.60)
0.56
- >95%
Braid

*Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.

ELECTRICAL PERFORMANCE
Model Cond.
D.C.R.

ohm/1000ft
(ohm/100m)
Shield
D.C.R.

ohm/1000ft
(ohm/100m)
Nom.
Cap.
***
pF/ft
(pF/m)
Nom.
Cap.

pF/ft
(pF/m)
Nom.
Imp.

ohm
Nom.
Atten.
@3MHz

dB/100m
Group
Delay
Time
nS/ft
(nS/m
DA206 <10.1
(<3.3)
<4.3
(<1.4)
14.6
(48)
22.3
(73)
110 2.2 -

***Capacitance between conductors.
†Capacitance between conductors to shield.

View Specifications

View PDF brochure for Canare DA206 110 Ohm AES/EBU Digital Audio Cable - BLUE - 100m Roll
