Audiocenter's new S3118A is an active DSP-controlled compact 18" subwoofer, featuring 3 low-pass filters at 80Hz, 100Hz, and 120Hz easily configurable for different venues and music styles. Including a phase switch, XLR input and output, 134dB, 2000W peak
| Loading... | ||||||
Audiocenter S3118A Active DSP-Controlled Compact Subwoofer
Audiocenter's new S3118A is an active DSP-controlled compact 18" subwoofer, featuring 3 low-pass filters at 80Hz, 100Hz, and 120Hz easily configurable for different venues and music styles. Including a phase switch, XLR input and output, 134dB, 2000W peak.
Many Features
This single 18" subwoofer has many features to ensure quality for long term use, including its Class D amplifier and DSP controlled crossover. There are many built-in protection systems, with DC, short circuit, overheat, input overload, output overload, soft startup, overvoltage, and undervoltage protection systems on board.
Audiocenter
Audiocenter are a global audio company specialising in the design and manufacturing of high performance power amplifiers and loudspeakers. The range of solutions includes everything from small PA systems with high SPL powered speakers, inbuilt EQ and mic preamps, to large scale line array systems for festivals and arenas. Audiocenter are committed to incorporate cutting edge design and technology into their products, including top shelf Class D amplification and advanced digital signal processors (DSP). Adhering to the principle of standing on the shoulders of giants, Audiocenter integrates top European R&D teams and top European speaker and electronic suppliers.
Specifications:
| Type | Active DSP-controlled Compact Subwoofer |
| Frequency Response (-6dB) | 30Hz-140Hz |
| Maximum Calculated SPL/1M (Continuous/Peak) | 128dB/134dB |
| LF | Customised 18” driver, 4” voice coil |
| AMPLIFIER | |
| Amplifier Circuitry | Class D |
| Power (Peak) | 2000W |
| Frequency Response (1W 8Ω 2ch) | 20Hz-20kHz(±0.5dB) |
| Intermodulation Distortion | ＜0.05% |
| Total Harmonic Distortion | ＜0.05% |
| Protection | DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection |
| Cooling System | Cooling with fans, air convection |
| DSP | |
| Processor | 48kHz signal sampling frequency, 24bit precision |
| Presets | 80Hz, 100Hz, 120Hz |
| Crossover | Controlled by DSP |
| Output/Input | |
| Signal Input | 1× female XLR |
| Signal Output | 1× male XLR |
| Power Input | IEC power connector |
| Working Voltage | 100V~130V or 220V~240V （±10%,50/60Hz） |
| Power consumption (1/8 output power) | 120W |
| CABINET | |
| Cabinet Material | CNC made of excellent wood |
| Cabinet Color | Black is the default color. Contact Audiocenter for customization |
| Pole Mount | M20 base Φ35mm |
| Dimension (W × H × D) | 510mm × 632mm × 695mm |
| Net Weight | 39kg |
